PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
2. PRODUCT DATA SHEET
2.1 R22/R407C
Model (Indoor & Outdoor)
EMD 27 & OU6-27 RC R22
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 26600 27300
Capacity
Kw 7.8 8.0
Power input Kw 2.8 2.4
COP W/W 2.79 3.28
Power supply V/Hz/Ph 230V/50Hz/1PH
Rated current A 11.6 10.0
Starting current A 67
Circuit breaker rating A 20
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 900 800 700
Air flow * H/ M/ L M³/Hr 1800 1560 1300
External static pressure Min-Max Pa 25 - 70
Sound power level ** H/ M/ L dBa 68.2 65.5 61.3
Sound pressure level *** H/ M/ L dBa 54.3 51.5 48.5
Moisture removal Lt/Hr 1.7
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 785 400 595
Weight Kg 32
Package dimensions W/ H / D mm 825 425 610
Package weight Kg 34
Units per pallet Units 8
INDOOR
Stacking height Units 4
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 1
Fan speeds H / L RPM 920
Air flow H / L M³/Hr 2350
Sound power level H / L dBa 69
Sound pressure level *** H / L dBa 62
Dimensions W/ H / D mm 900 580 340
Weight Kg 64
Package dimensions W/ H / D mm 985 640 410
Package weight Kg 67
Units per pallet Units 9
Stacking height Units 3
Refrigerant type R22
Charge / Distance Kg/ M 2.1/ 7.5
Additional charge per 1 meter Grams 25
Liquid line Inch 3/8
Suction line Inch 5/8
Max. tubing length Meter 25
OUTDOOR
Connections
between
units
Max. height difference Meter 10
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W)
