Oven Injector
The oven burner is xed in its cradle by a single clip that is placed
on the left-hand side of the burner. Pull the clip (Figure 6) further
left, and with your other hand, lift the burner up holding from
the thermocouple/spark plug holder. The injector is placed on
the right side of the burner cradle. Repeat the same procedure
for both Main and Top Oven (if present) burners.
Remove the injectors with a 7mm spanner and replace the
injector with the ones from the spare set, with corresponding
diameters suitable to the type of gas that is going to be used,
according to the information chart (which is also supplied in the
gas conversion kit).
Clip
