22 Rascal 309 & 329LE Scooter Owner’s Manual & Service Record
Technical Specification - Rascal 309 Scooter
Wheelchair type Class
Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1430 (56) x 650 (26) x 1020 (40)
Dimensions seat r
emoved tiller folded length x width x height mm (in) 1430 (56) x 650 (26) x 730 (29)
Maximum carrying capacity kg (lb) 136 (300)
Mass (weight) including batteries kg (lb) 42 (93)
Battery voltage and capacity
volts and ampere hours 12V 33Ah x 2
Type of seat Standard Adjustable armrest and height
Mass (weight) of seat kg (lb) 12.5 (28)
Wheel size front/rear mm (in) Front wheel 260 x 76 (10 x 3)
Rear wheel 305 x 76 (12 x 3)
Type of tyres type Pneumatic
Tyre Pressures normal front/rear p.s.i. (bar) 35 (2) / 35 (2)
Tyre Pressures maximum - not to be exceeded front/rear p.s.i. (bar) 50 (3.5) / 50 (3.5)
Maximum speed km/h (m.p.h.) 9.6 (6)
Minimum braking distance from maximum speed metres 2.3
Range on full charge and flat ground km (miles) Up to 40 (25)
The turn-around width m (ft) 1.4 (4.6)
The maximum safe slope degrees of slope 10˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 10˚
Ground clearance mm (in) 100 (4)
Maximum obstacle climbing ability mm (in) 90 (3.5)
Maximum safe descendable kerb height mm (in) 90 (3.5)
