Technical Specification - Rascal 329LE Scooter
Wheelchair type Class
Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1470 (58) x 645 (25) x 1300 (51)
Dimensions seat r
emoved tiller folded length x width x height mm (in) 1470 (58) x 645 (25) x 730 (29)
Maximum carrying capacity kg (lb) 159 (350)
Mass (weight) including batteries kg (lb) 74 (163)
Battery voltage and capacity
volts and ampere hours 12V 73Ah x 2
Type of seat Captain Adjustable armrest and height
Mass (weight) of seat kg (lb) 19.5 (43)
Wheel size front/rear mm (in) 305 x 76 (12 x 3) / 305 x 76 (12 x 3)
Type of tyres type Pneumatic
Tyre Pressures normal front/rear p.s.i. (bar) 35 (2) / 35 (2)
Tyre Pressures maximum - not to be exceeded front/rear p.s.i. (bar) 50 (3.5) / 50 (3.5)
Maximum speed km/h (m.p.h.) 12.9 (8)
Minimum braking distance from maximum speed metres 2.6
Range on full charge and flat ground km (miles) Up to 56 (35)
The turn-around width m (ft) 1.8 (5.8)
The maximum safe slope degrees of slope 10˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 10˚
Ground clearance mm (in) 115 (4.5)
Maximum obstacle climbing ability mm (in) 90 (3.5)
Maximum safe descendable kerb height mm (in) 90 (3.5)
