❏ Great Planes RimFire
™
28-30-950 Brushless Out-runner
Motor (GPMG4560)
❏ Great Planes Silver Series 25A Brushless ESC 5V/2A
BEC (GPMM1820)
❏ Great Planes 10x3.5 PowerFlow
™
Propeller (GPMQ6655)
(draws 15 amps max.)
❏ Great Planes 3.5mm Male/2.5mm Female Bullet
Connector Adapters (GPMM3122)
❏ Great Planes 3mm to 5mm Prop Adapter (GPMQ4959)
Battery Pack & Accessories
❏ Great Planes LiPo 1250mAh 11.1V 15C Discharge
w/Balance (GPMP0713)
❏ Great Planes LiPo 1500mAh 11.1V 15C Discharge
w/ Balance (GPMP0717)
A LiPo-compatible charger is required for these batteries,
along with a cell balancer. We recommend:
❏ Great Planes Equinox
™
1-5 cell LiPo cell balancer
(GPMM3160)
❏ Great Planes PolyCharge4
™
LiPo battery charger
(GPMM3015) OR Great Planes PolyCharge DC LiPo
battery charger (GPMM3010)
Required Adhesive & Building Supplies
This is the list of adhesive and building supplies required to
fi nish the SPAD XIII EP.
❏ 1/2 oz. [15g] Thin Pro
™
CA (GPMR6001)
❏ 1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏ R/C-56 Glue 4oz (JOZR5007)
❏ Denatured alcohol
❏ Drill bits: #55 [1.3mm], 1/16" [1.6mm]
❏ #1 Hobby knife (HCAR0105)
❏ #11 blades (5-pack, HCAR0211)
❏ Hobbico
®
Steel T-Pins 1" (100) (HCAR5100)
❏ Great Planes Pro Thread locker (GPMR6060)
❏ CA applicator tips (HCAR3780)
❏ 220 grit sandpaper
❏ Bru Line
®
hemostat – curved 5-1/2" (BRUR1303)
Optional Supplies & Tools
Here is a list of optional tools mentioned in the manual that
will help you build the SPAD XIII EP.
❏ 21
ST
Century
®
sealing iron (COVR2700)
❏ 21
ST
Century iron cover (COVR2702)
❏ 2 oz [57g] spray CA activator (GPMR6035)
❏ 4 oz [113g] aerosol CA activator (GPMR634)
❏ Masking tape (TOPR8018)
❏ CA debonder (GPMR6039)
❏ Great Planes Double-Sided Servo Tape 1"x3' (GPMQ4442)
❏ Panel Line Pen (TOPQ2510)
❏ Rotary tool (Dremel
®
) with cutoff wheel
❏ Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
❏ Builder’s Triangle Set (HCAR0480)
❏ AccuThrow
™
Defl ection Gauge (GPMR2405)
❏ Hobbico 12 Volt DC power supply (HCAP0250)
❏ Green 3M
®
Scotch Brite
™
IMPORTANT BUILDING NOTES
• When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom fi t
the part as necessary for the best fi t.
• Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
• Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following steps
to get another view of the same parts.
• The stabilizer and wing incidences and motor thrust
angles have been factory-built into this model. However,
some technically-minded modelers may wish to check
these measurements anyway. To view this information visit
the web site at www.greatplanes.com and click on
“Technical Data.” Due to manufacturing tolerances which
will have little or no effect on the way your model will fl y,
please expect slight deviations between your model and
the published values.
KIT INSPECTION
Before starting to build inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not of
acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or
missing parts, use the part names exactly as they are written
in the Kit Contents list.
Great Planes Product Support
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Telephone: (217) 398-8970, ext. 5
Fax: (217) 398-7721
E-mail: airsupport@greatplanes.com
