SPECIFICATIONS
Specifications With cable
Dimensions
Measurements H x W x D (without Dock) 17 3/4“ x 7“ x 5“ (450 mm x 180 mm x 126 mm)
Cable length 24‘-7“ (7.5 m)
Installation type Wall, pole
Weight (without Dock) 14.1 lbs (6.4 kg)
Environment
Enclosure rating Type 3S
Ambient temperature
-22 °F to +122 °F (-30 °C to +50 °C) full load
Thermal overload protection: output power reduced at higher temperatures
Storage temperature -22 °F to +176 °F (-30 °C to +80 °C)
Mains connection
Voltage supply 240 V AC split phase
Connected load up to 7.6 kW
Charging ports
Number of charging ports 1
Output power up to 7.6 kW
Cable Type 1 SAE J1772
User interface
Display
LED ring for charging level; 2 status LEDs: vehicle link;
1 status LED as touch button: Bluetooth
®
(disabled)
Backend link (disabled) WLAN with 2.4 GHz b/g/n with WPA2 (disabled)
Backend protocol (disabled) OCPP v1.6 via WLAN (disabled)
App linking (disabled) Via Bluetooth interface; Bluetooth Class 1 and 2 (power level) (disabled)
Protective equipment
AC fault monitor GFCI Integrated (20 mA rms for AC)
Short circuit / overload protection Needs to be installed as described in the installation instructions of the Dock
