ElectrIQ EIQMOBISOLO25 - Built-in Furniture Requirements

8
BUILT-IN FURNITURE
Note:
The bracket and bottom cabinet template are needed during installation
A
Overall Width
595mm
B
Overall Height
388mm
C
Overall Depth
410mm
D
Cutout Width
560mm
E
Cutout Height
380mm
F
Cutout Depth
500mm(min)
G
Drawer Clearance
10mm
H
Door Clearance
10mm
I
Side Wall Thickness
20mm
J
Notch Width
45mm
