13
English
T
his is a simple setup for stereo processing of the entire mix. Selecting the
Mic or the Auto settings for the formant input will provide plenty of sonic
possibilities. Use this setup only after you have explored all the sonic possibilities
of WarpFactory because cueing is not possible. The cueing limitation can be
minimized by bringing in the effect gradually with WarpFactorys mix control and
then making any adjustments from there.
The 1/4” output has a survo driver circuit which is capable of driving longer cables
to the power amp.
Line in
Line Out
to Crossover/Power Amp
Phono in
SET UP 3: POST MIXER3.1
