5. SPECIFICATIONS
INPUT SOURCE SOURCE SOURCE FORMANT FORMANT
Connectors: 1/4” TRS RCA(phono) RCA(line) 1/4”TS XLR
(balanced)
Max Input Level: +16.0 dBu -24.5 dBV +16.0dBu +16.0 dBu +3.5 dBu
Impedance: 66KΩ 48.5KΩ 66KΩ 20KΩ 2KΩ
OUTPUT EFFECT OUTPUT MIC BYPASS
OUTPUTS
Connectors: 1/4”TRS bal RCA XLR
Impedance: 450Ω 1K0Ω 210Ω
Max Output Level: +16.0 dBu +16.0 dBu +13.0 dBu
PERFORMANCE 1/4” PHONO RCA MIC BYPASS
Dynamic Range: >90db >78db <85db >115db
THD: <0.04% <0.05% <0.05% <0.001%
Frequency Response:
10Hz-14.3kHz 10Hz-14.3kHz 10Hz-14.3kHz
10Hz-30kHz
A to D Conversion: 18bit/31.250 kHz Sampling rate CMRR > 50db
D to A Conversion: 18bit/31.250 kHz Sampling rate
POWER CONSUMPTION
30 watts VOLTAGE FREQUENCY FUSE
100 V 50/60 Hz 250mA 250V Slow blow
120 V 50/60 Hz
230 V 50/60 Hz 125mA 250V “T”
240 V 50/60 Hz
Actual measurements are subject to change
