# = Functional Part/ Piéces fonctionnelles 9 12/02
* = Non-Illustrated Part/ Piéces non-illustrées
CFEF372C Publication No.
5995382834
DOOR / PORTE
A = CFEF372C (CFEF372CS1)
B = CFEF372C (CFEF372CB1)
C = CFEF372C (CFEF372CQ1)
POS. NO PART NO DESCRIPTION
1 318180310 A B C Bracket,trim mtg
2 318180312 A B C Bracket,upper trim mtg
3 318178322 A - - Trim,door ,white ,RH side
3 318178324 - B - Trim,door ,black ,RH side
3 318178328 - - C Trim,door ,bisque ,RH side
3A 318178323 A - - Trim,door ,white ,LH side
3A 318178325 - B - Trim,door ,black ,LH side
3A 318178329 - - C Trim,door ,bisque ,LH side
3B 318176646 A - - Trim,door ,white ,top
3B 318176647 - B - Trim,door ,black ,top
3B 318176648 - - C Trim,door ,bisque ,top
4 318187717 A - - Panel,door front assy ,glass ,white ,with lower trim
4 318187718 - B - Panel,door front assy ,glass ,black ,with lower trim
4 318187720 - - C Panel,door front assy ,glass ,bisque ,with lower trim
6 318057031 A B C Shield,insullation ,black ,door
7 318133706 A B C Insulation,oven door
7A 318133707 A B C Insulation,oven door ,cavity
9 318157013 A B C Liner,door
10 08011955 A B C Screw,10-24 x 0.375 ,square drive
12 318053105 A B C Seal,oven door
16 5303310533 A B C Glass,oven door ,6.50 x 15.50 ,inner ,heat barrier
17 318139000 A B C Spacer,oven door glass ,inner frame
18 5303310531 A B C Gasket,door glass seal ,inner
22 5303310511 A B C Bar,glass retainer
23 318024700 A B C Hinge,oven door
31 5303310536 A B C Latch,oven door
39 316203001 A - - Handle,door ,white
39 316203000 - B - Handle,door ,black
39 316203003 - - C Handle,door ,bisque
56 5303300265 A B C Screw,8-18 x 0.500 ,chrome
64 5304417120 A B C Tape,0.762 m ,Neoprene
77 318043100 A B C Bracket,trim ,handle ,(2)
* 08016432 A B C Screw,truss head ,8-18 x 0.375
* 5303211311 A B C Screw,8 x 0.500
* 5303307980 A B C Screw,8-32 x 0.437
