1
Grid
2
Filter
3
Filter housing
4
Hob
5
Connector
6
Cabinet back wall fitting
7
Tube
8
Adapter
4.2 Cooking surface layout
1
Induction cooking zone
2
Control panel
3
Flexible induction cooking area
consisting of four sections
4
Hood
4.3 Control panel layout
1
3
4
5
1516
76 148 9 1110 12 13
2
Use the sensor fields to operate the appliance. The displays, indicators and sounds
tell which functions operate.
Sen‐
sor
field
Function Description
1
On / Off To activate and deactivate the appliance.
2
Timer To set the function.
ENGLISH 11
