FOR THE USER
Description of the appliance
1 Worktop
2 Programme chart
3 Door opening button
4 Mains-On light
5 ON/OFF button
6 Low Temperature button
7 Buzzer OFF button
8 Start button
9 Control lights
10 Programme Selector Dial
11 Rating Plate
12 Fluff filter
13 Adjustable feet
14 Side vent outlets
15 Ring nut
16 Rear vent outlet
13
12
11
110
2
34 6 7
8 9
EDE 401 E
5
14
15
16
