Electrolux EDE420E - Description of the Appliance

6
Description of the appliance
1 Worktop
2 Programme chart
3 MainsOn light
4 ON/OFF button
5 Low Temperature button
6 Buzzer OFF button
7 Start button
8 Control lights
9 Programme Selector Dial
10 Rating Plate
11 Fluff filter
12 Adjustable feet
013 Side vent outlets
014 Ring nut
015 Rear vent outlet
12
11
10
19
2
3
5 6
78
4
13
14
15
