• Cut off the mains cable and discard it. • Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
The graphics below is just a
general product overview.
For more detailed
information, refer to other
chapters and/or documents
provided with the appliance.
4
3
7
8
10 9
56
11
1
2
1
Upper spray arms
2
Lower spray arm
3
Filters
4
Rating plate
5
Salt container
6
Air vent
7
Rinse aid dispenser
8
Detergent dispenser
9
Cutlery basket
10
Lower basket
11
Upper basket
4. CONTROL PANEL
1 3
4 5
2
6
1
On/Off button
2
Delay Start button
