55
1 Assemble the clip snap onto the base.
click!
2 Press in both assembled clip modules into the kick panel in the orientation as shown below.
click!
3 Make sure both clip modules are in the same orientation after installation.
4 Clip the kick panel onto the front feet of the appliance. Make sure the kick
panel snaps onto the larger section of the front feet.
snap!
INSTALLATION OF EFE914, EFEP916 & EFEP956 (CONTINUED)
