Electrolux EGS64041X - 3.8 Assembly

'L'. It must always be connected to the
network phase. There must be no cut or
stray strands of wire present. The cord
clamp must be correctly attached to the
outer sheath.
3.8 Assembly
1.
2.
3.
min. 55 mm
min. 650 mm
550 mm
2
0
+
min. 100 mm
30 mm
4
70
mm
2
0
+
min. 600 mm
4.
50 mm
min. 400 mm
5.
6.
7.
ENGLISH 11
