Electrolux EH7GL4XCN - Product Description; Control Panel

3. PRODUCT DESCRIPTION
3.1 General overview
5
4
3
2
1
1
11
6
5
4
7
9
10
8
2 3
1
Control panel
2
Electronic programmer
3
Heated drawer indicator (selected models
only)
4
Knobs for the hob
5
Socket for the food sensor
6
Heating element
7
Lamp
8
Fan
9
Drawer
10
Shelf support, removable
11
Shelf positions
3.2 Accessories
• Wireshelf
For cake tins, ovenproof dishes, roast
dishes, cookware / dishes.
• Baking tray
For moist cakes, baked items, bread, large
roasts, frozen meals and to catch dripping
liquids, e.g. fat when roasting food on wire
shelf.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.
• Food Sensor
To control cooking based on the
temperature inside the food.
• Storage drawer
The storage drawer is below the oven
cavity.
WARNING!
The storage drawer can become hot
when the oven operates. Do not store
any flammable materials in the
drawer.
4. CONTROL PANEL
4.1 Control panel overview
21 3 4 5 8 9 10 1176
