When you have cut it to length (add some
mm), push the two ends together.
Assembly
min. 500 mm
min.
50 mm
min.
50 mm
min.
5 mm
min. 55mm
min.
55mm
380
+1
mm
880
+1
mm
R 5mm
min.
25 mm
min.
5 mm
min.
20 mm
