3. PRODUCT DESCRIPTION
3.1 Cooking surface layout
120/210
mm
120/210
mm
145 mm
145 mm 120/180
mm
120/180
mm
1
1
1 1
2
1
Cooking zone
2
Control panel
3.2 Control panel layout
1 2 3 4 5 6 7 8
911 10
Use the sensor fields to operate the appliance. The displays, indicators and sounds
tell which functions operate.
Sen‐
sor
field
Function Comment
1
ON / OFF To activate and deactivate the hob.
2
Lock / The Child Safety
Device
To lock / unlock the control panel.
3
STOP+GO To activate and deactivate the function.
4
- To activate and deactivate the outer ring.
5
- Heat setting display To show the heat setting.
6
- Timer indicators of cook‐
ing zones
To show for which zone you set the time.
7
- Timer display To show the time in minutes.
