2. PRODUCT DESCRIPTION
2.1 General overview
3
5
1 2
4
120/175/210 mm
120/180 mm
145 mm
145 mm
1
Cooking zone
2
Cooking zone
3
Cooking zone
4
Control panel
5
Cooking zone
2.2 Control panel layout
1 2 3 4 5 6 7
891011
Use the sensor fields to operate the appliance. The displays, indicators and
sounds tell which functions operate.
sensor field function
1
To activate and deactivate the appliance.
2
To lock/unlock the control panel.
3
A heat setting display To show the heat setting.
4
Timer indicators of cooking
zones
To show for which zone you set the time.
5
The timer display To show the time in minutes.
6
/
To increase or decrease the heat setting.
7
To activate and deactivate the outer ring.
8
/
To increase or decrease the time.
9
To select a cooking zone.
