DESCRIPTION OF THE APPLIANCE
Cooking surface layout
145 mm
145 mm
120/175/210 mm
1
4
3
5
120/180 mm
2
1 Single cooking zone 1200 W
2 Double cooking zone 700/1700 W
3 Single cooking zone 1200 W
4 Control panel
5 Triple cooking zone 800/1600/2300 W
Control panel layout
1 2 3 4 5 6 7
891011
Use the sensor fields to operate the appliance.
Displays, indicators and sounds tell which functions operate.
sensor field function
1
starts and stops the hob
2
locks/unlocks the control panel
3
a heat setting display shows the heat setting
4
cooking zones' indicators of timer show for which zone you set the time
5
the timer display shows the time in minutes
6
/
increase or decrease heat setting
7
starts and stops the outer ring
8
/
increase or decrease the time
9
selects the cooking zone
10
starts and stops the outer rings
11
starts and stops STOP+GO
