Electrolux EI23BC80KS - Removing the Doors; Removing Refrigerator Doors; Removing Freezer Drawer

11
Once both doors are in place, ensure they are aligned
with each other and level (please see the “Installation”
section for more details), and replace the top hinge
cover.
CAUTION
Be sure doors are set aside in a secure position
where they cannot fall and cause personal injury,
or damage to the doors or handles.
To remove the refrigerator doors:
1 Tracelightlyaroundthedoor’stophingeswitha
pencil. This makes reinstallation easier.
2 Disconnect the harness by grasping both sides of
the connector firmly, depress the latch, and pull
apart. Remove the two (2) screws from the top
hinge. Lift the door off of the bottom hinge and
set it aside.
Lower Hinge Removal
3 Unscrew the three (3) lower hinge screws and
hinge if necessary.
Removing the Doors
Getting through narrow spaces
If your refrigerator will not fit through an entrance area,
you can remove the doors. Check first by measuring the
entrance.
To prepare for removing the doors:
1 Make sure the electrical power cord is unplugged
from the wall outlet.
2 Open the freezer drawer and remove the toe
grille (see “Installation” section).
3 Remove any food from the door shelves and
close the doors.
Removing Freezer Drawer
1 Open freezer drawer.
2 Remove drawer screws on right and left sides
(two (2) screws on each side).
3 Lift drawer up and out to remove.
CAUTION
Drawer is heavy. Use caution when lifting.
To reinstall the right door, reverse the above steps.
