Electrolux EI24BL10QS User Manual

14
To Add or Remove a Shelf:
Remove stored product from the shelf. Do not try to remove a loaded shelf from the
appliance. Grasp the shelf front with both hands, rotate the front upward and lift out.
(See Figure 13b). To install a shelf insert the shelf in the appliance and insert the hooks
into the shelf support slots and drop the shelf down so the tabs engage the bottom of
the slots.
CAUTION
Make sure your cantilever shelf is secure on the shelf supports by pressing
down on the shelf before loading the shelf.
CAUTION
Never try to move a loaded shelf, remove everything from the shelf before
moving. Use both hands when moving the shelf.
Storage
Tall bottle
storage
area
Rear
tang
(hook)
on shelf
Shelf support
slot
Installed shelf
tang
Grasp the shelf by the front with
both hands and rotate the front
of the shelf up, then lift the shelf
up and remove the shelf from the
shelf ladders.
To remove the wine shelf from the frame:
Extend the wine shelf from the frame until
it stops. Lift the front of the shelf to
disengage the side rails and remove the shelf.
Figure 13a
Figure 13
Figure 13b
Figure 14

Electrolux EI24BL10QS Specifications

General

Color	stainless steel
Temperature Control	electronic
Child Lock	yes
Smart Home	no
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	23.63 inches
Height	34.75 inches
Width	23.88 inches
Net Weight	118 pounds
