5
Installation
Installing the Beverage Center
Your Electrolux beverage center has been designed for either free-standing or built-in
installation. When built-in, your beverage center does not require additional air space for
top, sides or rear. In either case, the front grille must NOT be obstructed.
Width Height Depth
23
7
/
8
inch 33
3
/
4
- 34
3
/
4
inches 26
3
/
8
inch
Unit Dimensions
NOTE
To ease unit installation and removal, it is recommended that the cabinet rough
opening dimensions be increased by at least ¼ inch over the dimensions given for
your unit.
NOTE
All units require zero clearance when installed flush with a cabinet or wall. Electrolux
stainless steel models require a minimum 2
7
⁄
8
inch handle clearance when installed
against a wall or cabinet that extends beyond the front edge of the unit.
Top
Vi ew
Side
View
Front
View
46 13/32
"
23 7/8"
21/2"
26 3/8"
23 23/32"
21 1/2"
33 3/4"
Adjustableto
34 3/4"
23 7/8"
35/16"23/4"
