Installing Door Handles
Door Handle Mounting Instructions
1 Remove handles from carton and any other protective
packaging.
2 Position freezer handle end caps over upper and
lowerpre-installedshoulderbolts(A)thatare
fastened into door, ensuring the holes for the set
screws are facing towards the refrigerator door.
3 While holding handle firmly against door, fasten upper
andlowerAllensetscrews(B)withsupplied 
Allenwrench.
4 Repeat steps 2 and 3 to install refrigerator handle.
Ensure the holes for the set screws are facing towards the freezer door.
A
B
Freezer Lower End Cap
A
B
Refrigerator Lower End Cap
A
B
Freezer Upper End Cap
A
B
Refrigerator Upper End Cap
NOTE
Allsetscrewsshouldbetightenedandsub-ush(Allensetscrewshouldbeseatedjustbelow
the surface of the end cap) of handle end cap. The end caps should be drawn tight to freezer and
refrigerator doors with no gaps.
