Electrolux EI32AR65JS User Manual

7
Installing Door Handle
Door Handle Mounting
Instructions
1. Remove handle from carton and any other
protective packaging.
2. Position refrigerator handle end caps over upper
and lower pre-installed shoulder bolts (A) that
are fastened into door, ensuring the holes for the
set screws are facing towards the outside of door
if a single unit installation or the freezer door (if
installing the matching freezer)
3. While holding handle fi rmly against door, fasten
upper and lower Allen set screws (B) with supplied
Allen wrench.
4. Repeat steps 2 and 3 to install freezer handle
(if installing the matching freezer). Ensure the
holes for the set screws are facing towards the
refrigerator door.
Toe Grille Removal
To remove the toe grille, use a Phillips head
screwdriver and remove the two screws holding the
toe grille to the cabinet. Then pull the toe grille away
from the unit.
Leveling
• The refrigerator must have all bottom corners
resting fi rmly on a solid fl oor.
• The fl oor must be strong enough to support a fully
loaded refrigerator.
• It is VERY IMPORTANT for your refrigerator
to be level in order to function properly. If the
refrigerator is not leveled during installation,
the door may be misaligned and not close or
seal properly, causing cooling, frost or moisture
problems.
Leveling instructions continued on next page.
A
B
All set screws should be tightened and sub-fl ush
(Allen set screw should be seated just below the
surface of the end cap) of handle end cap. The end
caps should be drawn tight to refrigerator door with
no gaps.
Single Unit Installation
Matching Refrigerator and Freezer Door Handle
Installation
Remove
Screws
Toe Grille
