38
INSTALLATION
IMPORTANT
Do not remove the torque screws at the
twelve and 6 o’clock positions.
X
X
180°
4. Remove remaining eight screws using
a #2 square bit driver. Save the screws
for reinstallation.
5. Lift the metal ring and rotate it
180 degrees, setting it back on the
inner frame. Ensure gasket has not
separated from the metal ring.
6. Make sure “THIS SIDE UP” AND “THIS
SIDE DOWN” on the metal ring point in
the corresponding directions.
3. Locate and remove the two screws
holding the striker. Save the screws
and latch for reinstallation.
