EME2725 U English
9
1. Place the turntable support on the cavity
Bottom.
2. Place the turntable on top of the turntable
support as shown in the diagram. Make sure that
turntable hub is securely locked in the turntable
shaft. Never place the turntable upside down.
• Both turntable and turntable support must
always be used during cooking.
• All food and containers of food are always
placed on this turntable for cooking.
• This turntable rotates clockwise and
anticlockwise; this is normal.
Turntable
Roller rest
Drive Shaft
6
2
3
1
4
4
5
7
8
1.
Cooking compartment. Wipe the compartment
clean after using the oven.
2.
Viewing window. Food can be checked while the
microwave oven is in operation.
3.
Oven door. The door must always be firmly
closed while cooking.
4.
Latch hook, Safety interlock system.
5.
Control panel.
6. Turntable support. Place the support on the floor
of the cooking chamber to support the turntable.
7. Turntable. Made of special heat-resistant glass.
Food in a suitable container is placed on this tray
for cooking. Do not use the oven without the
turntable.
8. Drive shaft for turntable.
The Microwave and Accessories
Name and function of parts Turntable Installation
