Electrolux EOB3434BOX - Control Panel; Buttons; Display

4. PRODUCT DESCRIPTION
4.1 General overview
9
8
13
12
5
4
1
2
3
4 7631 52
10
11
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Plus Steam
8
Heating element
9
Lamp
10
Fan
11
Cavity embossment
12
Shelf support, removable
13
Shelf positions
4.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Combi pan
For cakes and biscuits. To bake and
roast or as a pan to collect fat.
• Telescopic runners
For shelves and trays.
5. CONTROL PANEL
5.1 Buttons
Sensor field / Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
PLUS STEAM To turn on the True Fan Cooking PLUS
function.
5.2 Display
A B C
A. Clock functions
B. Timer
C. Clock function
ENGLISH 9
