Electrolux EOD3C70TK User Manual

Baking tray/ Deep pan:
Push the baking tray / deep pan between
the guide bars of the shelf support.
Wire shelf and baking tray / deep pan
together:
Push the baking tray / deep pan between
the guide bars of the shelf support and
the wire shelf on the guide bars above.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
9.2 Telescopic Runners
Keep the installation
instructions for the
telescopic runners for future
use.
With telescopic runners you can put in
and remove the shelves more easily.
CAUTION!
Do not clean the telescopic
runners in the dishwasher.
Do not lubricate the
telescopic runners.
1. Pull out the right and left hand
telescopic runners.
°C
2. Put the wire shelf on the telescopic
runners and carefully push them into
the oven.
°C
Make sure you push back the telescopic
runners fully in the oven before you close
the oven door.
www.electrolux.com14

Electrolux EOD3C70TK Specifications

General

Door hinge	down
Cord length	1.6 m
Control type	Rotary, Touch
Product color	Black
Built-in display	Yes
Control position	Top right / left
Oven door opening	Drop down opening
Appliance placement	-
Connected load	2990 W
AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Energy efficiency scale	A+++ to D
Energy consumption (conventional)	0.95 kWh
Energy consumption (forced convection)	0.81 kWh
Lamp type	Halogen
Bulb power	40 W
Lamps quantity	1 lamp(s)
Package depth	670 mm
Package width	635 mm
Package height	654 mm
Package weight	30800 g
Number of baking trays	1
Oven size	Medium
Oven type	Electric
Total oven power	- W
Bottom heating power	1000 W
Oven thermostat range	50 - 275 °C
Total oven(s) interior capacity	72 L

Weight and Dimensions

Depth	569 mm
Width	596 mm
Height	594 mm
Weight	29800 g
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	600 mm
