Electrolux EOD3C70TK User Manual

Cabinet minimum
height (Cabinet un‐
der the worktop
minimum height)
590 (600) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of
the appliance
594 mm
Height of the back
of the appliance
576 mm
Width of the front of
the appliance
595 mm
Width of the back of
the appliance
559 mm
Depth of the appli‐
ance
569 mm
Built in depth of the
appliance
548 mm
Depth with open
door
1022 mm
Ventilation opening
minimum size.
Opening placed on
the bottom rear side
560x20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 4x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance is supplied with a main
plug and a main cable.
Cable types applicable for installa‐
tion or replacement for Europe:
H07 RN-F, H05 RN-F, H05 RRF, H05
VV-F, H05 V2V2-F (T90), H05 BB-F
For the section of the cable refer to the
total power on the rating plate. You can
also refer to the table:
Total power (W) Section of the ca‐
ble (mm²)
maximum 1380 3 x 0.75
maximum 2300 3 x 1
ENGLISH 5

Electrolux EOD3C70TK Specifications

General

Door hinge	down
Cord length	1.6 m
Control type	Rotary, Touch
Product color	Black
Built-in display	Yes
Control position	Top right / left
Oven door opening	Drop down opening
Appliance placement	-
Connected load	2990 W
AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Energy efficiency scale	A+++ to D
Energy consumption (conventional)	0.95 kWh
Energy consumption (forced convection)	0.81 kWh
Lamp type	Halogen
Bulb power	40 W
Lamps quantity	1 lamp(s)
Package depth	670 mm
Package width	635 mm
Package height	654 mm
Package weight	30800 g
Number of baking trays	1
Oven size	Medium
Oven type	Electric
Total oven power	- W
Bottom heating power	1000 W
Oven thermostat range	50 - 275 °C
Total oven(s) interior capacity	72 L

Weight and Dimensions

Depth	569 mm
Width	596 mm
Height	594 mm
Weight	29800 g
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	600 mm
