Electrolux EOD3H50TH - Product Description; Control Panel

4. PRODUCT DESCRIPTION
4.1 General overview
8
7
12
9
10
11
5
4
1
2
3
331 64 52
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Heating element
8
Lamp
9
Fan
10
Cavity embossment - Aqua cleaning
container
11
Shelf support, removable
12
Shelf positions
4.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.
• Telescopic runners
With the telescopic runners you can put in
and remove the shelves more easily.
5. CONTROL PANEL
5.1 Retractable knobs
To use the appliance press the knob. The
knob comes out.
5.2 Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
ENGLISH 9
