Electrolux EOD3H54X - Control Panel; Sensor Fields and Buttons

4. PRODUCT DESCRIPTION
4.1 General overview
9
8
13
12
5
4
1
2
3
4 7631 52
10
11
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Plus Steam
8
Heating element
9
Lamp
10
Fan
11
Cavity embossment - Aqua cleaning
container
12
Shelf support, removable
13
Shelf positions
4.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Combi pan
For cakes and biscuits. To bake and
roast or as a pan to collect fat.
• Telescopic runners
With the telescopic runners you can
put in and remove the shelves more
easily.
5. CONTROL PANEL
5.1 Retractable knobs
To use the appliance press the knob.
The knob comes out.
5.2 Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
To turn the True Fan Cooking PLUS function on and off.
ENGLISH 9
