34
Electrolux 818 16 21--02/3
Model ER9096
Hanging half-shelf
The half-shelf can be moved sideways. It can be
hung under all door shelves, except the lowest one.
Model ER9096
Cooling Rack for Beverages
To achieve maximum cooling in t he cooling rack,
heed the following:
· Place the rack immediately under the drip
channel.
· Be sure the rack is cold before placing bottles
and cans, that you want to cool, on it.
· Place large cans and bottles in the big
recesses i n the middle of the rack.
· Place small cans and bottles in the small
recesses close to the cabinet wall.
Do not
in a
freezer to achieve quicker cooling.
Do not put loads heavier than
6.5kg onto the shelf
.
Using the freezer
GB
To start the freezer and set the
correct temperature
Turn the thermostat control to the desired position.
MIN
The lowest position of the thermostat control results
in the highest temperature i nside the cabinet.
MAX
The highest position of the thermostat control results
in the lowest temperature inside the cabinet.
H :
Switched off.
Allow the cabinet to run for a period of 24 hours
whenever the temperature setting is changed. This
will allow t he temperature to stabilise inside the
cabinet.
Temperature inside the freezer
To ensure that foodstuff will keep for a long time, be
sure that the temperature inside the freezer is -18°C
or below. Please note, however, that the energy
consumption increases as the temperature decreases.
The built-in temperature display shows the warmest
temperature inside the freezer. If the temperature is
measured using a thermometer, put it between the
products since this will reflect the real temperature
in the frozen products. It is normal that the built-in
temperature display shows a temperature slightly
above that measured in other ways.
Switching off
Turn the control anti-clockwise past the click
position to "H".
Unplug the power supply plug from the wall socket
or, alternatively, remove the fuse.
