Electrolux ESF4500LOW - Control Panel; Panel Overview; Indicator Lights

9
Detergent dispenser
10
Cutlery basket
11
Lower basket
12
Upper basket
4. CONTROL PANEL
Program
Delay
Start
Option
1
2
3 5
78 6
4
1
On/off button
2
Program button
3
Programme indicators
4
Display
5
Delay button
6
Start button
7
Indicators
8
Option button
4.1 Indicators
Indicator Description
Washing phase. It comes on when the washing phase operates.
Drying phase. It comes on when the drying phase operates.
Multitab indicator.
Salt indicator. It is always off while the programme operates.
Rinse aid indicator. It is always off while the programme operates.
EnergySaver indicator.
