Compartment : this compartment is only used
for washing powder when a program has Prewash
or Stain.
Compartment : this compartment is used for
fabric conditioner and starching agent.
Compartment : this compartment is used for
washing powder on all programs.
6 electrolux product description / control panel
Detergent dispenser drawer
CONTROL PANEL
Program Selector Dial
See page 8.
See page 9.
See page 9.
See page 10.
See page 10.
Temperature Button
Spin Button
Prewash Button
Vapour Button
5
4
3
2
1
Display
See page 12.
See page 13.
See page 14.
Start/Pause Button
Time Manager Button
9
8
7
Delay
See page 11.
6
The detergent dispenser is divided into three
compartments. The table of Washing Program shows
which compartment to use.
Always add laundry detergents before switching the machine on and keep the dispenser
clean and dry, so that the detergent can be efficiently dispensed from the unit.
1 2 3 4 5 6 7 8 9
