Electrolux EWF1070M - Specification

SERVICE MANUL
EWF1070M
EWF1070W
Washing Machine
６
2-2. Specification
washing machines
EWF1070M
EWF1070W
Last update
1. Product identification
Description of appliance
Washing machine
Type of appliance(FS = standing, BI = built-in FS
Supplier own brand
Supplier bar code EAN
Commercial Brand / Model
Commercial bar code EAN
2. Key-Features
Energy efficiency class
A
Washing performance class
A
Spin efficiency class
B
Programs
n° 11
Capacity
Kg 7
Spin speed (max. / optional)
rpm 1000
Noise level（sound pressure level）
dB(A) 71.9
Energy consumption per wash circle kWh 1.19
Water consumption per wash cycle l 56
Residual dampness (spin result)
% 50%
Spin speed selector switch (steps)
rpm l
Spin speed variator (stepless)
rpm l
Adjustable thermostat (water temp. adjust from - to)
°C 90 - T
Drum capacity dry laundry / water kg / l 7/56
Auto water level adjust (depending on volume of filled in laundry) AWL
l
Washing time (max.) min 178
Washing temperatures (program-controlled)
°C Cold/30/40/50/60/90
Certification's (CE / ISO 9001 / ISO 9002)
CE / ISO 9001
Approvals (VDE/GS / TÜV/GS / IMQ) TÜV/GS (Rhl.)
* per average 200 wash cycles (EN50242) T= COLD
l
3.
Basics data
Unit dimensions (H x W x D) cm 84X59.5X61
Net weight kg 72
Voltage/frequency V/Hz 220-240V~50Hz
Input power / main fuse (intensity) W / A 2000/10
Work top / removable l/l
Control M = electromechanical, E = electronic, F = fuzzy
E
Inner cylinder S = stainless steel / Z = zinc coated
S
Outer cylinder P = Plastic / S = stainless steel
P
Door:
aesthetic (R = round, Y = big eye, Q = square)
Y
Diameter
cm 30
Outer door frame S= stainless steel / M = metal / P = plastic
P
Inner door G= glass / P= plastic
G
Detergent compartments n° 3
Removable compartment for liquid detergent -
Delay timer (from - to)
h 0.5-24
Self cleaning suds pump l
Water inlet hose cold water / hot water
l/-
