Electrolux EWF12844 - Product Description

PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Rating Label
14
Drum Leaf Lifter
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support + Transit Bolts
12
Back Feet (Fixed)
Transit Bolts
6 www.electrolux.com
To connect the drain
hose on the edge of a
sink.
Plastic caps
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
ACCESSORIES
Plastic hose guide
4
5
This machine is integrated drain design; lint will be drained out and don't need to clean the
filter regularly. If you would like to clean the filter, please contact your local Service
Center.
*
11
* +,
10
7
8
6
12
9
13
14
