Electrolux EWF14822 - Product Description

6 www.electrolux.com
PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Child Safety Device
Rating Label
14
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support (2pcs)
12
Level Adjustment Feet (Back)
Transit Bolts (3pcs)
To remove the transit
bolts.
To adjust levelling legs.
To connect the drain
hose on the edge of a
sink.
Plastic Caps
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
ACCESSORIES
Plastic Hose Guide
Spanner
3
5
4
2 1
9
8
7
1011
11
12
14
13
6
15
Drain Pump Filter
15
