FRIGIDAIRE MODEL SPECIFICATIONS
Model FAS182J2A3 FAS182J2A4 FAS184J2A1 FAS185J2A1 FAS224J2A1
Chassis Type Heavy Duty Top
Control
Heavy Duty Top
Control
Heavy Duty Top
Control
Heavy Duty Top
Control
Heavy Duty Top
Control
Capacity Features
BTU - Cooling
BTU - Heating
Moisture Removal
EER
18000/17800
-
5
8.8
18000/17800
-
5
8.8
18000/17800
-
5.5
9.7
18000/17800
-
5.5
9.7
22000/21600
-
6.5
8.5
Electrical Information
Voltage
Amps - Cooling
Amps - Heating
Watts - Cooling
Watts - Heating
Fuse/Breaker (Amps)
Receptacle Code
Wiring Diagram
Page #
230/208
9/10
-
2045/2020
-
15
B
309107703
42
230/208
9/10
-
2045/2020
-
15
B
309107703
42
230/208
8.5/9
-
1855/1815
-
15
B
309343701
44
230/208
8.5/9
-
1855/1815
-
15
B
309343701
44
230/208
11.5/12.5
-
2590/2550
-
20
C
309107703
42
Air Flow System
Capacitor-µ farads
Fan Motor Mfg.
Fan Motor Number
RPM/CMP (EVAP)
High
Medium
Low
Heat Only
7.5/370
Heshan
309630604
1120/565
1000/460
900/415
-
7.5/370
GE PSC
A478921
1120/565
1000/460
900/415
-
6/370
Heshan
309630603
950/480
830/420
770/390
-
6/370
Heshan
309630603
950/480
830/420
770/390
-
7.5/370
GE PSC
A478921
1120/500
1010/450
910/400
-
Refrigeration System
Compressor Mfg.
Compressor Number
Compressor Type
Overload Protector
Capacitor-µ farads
Refrigerant Charge
Restrictor Tube
Thermostat Type
Goldstar
QJ264KE23B
Rotary
A363771
30/370
29.5
A112104
Bulb
Bristol
H23B18SABCX
Reciprocating
Internal
30/370
29.5
A112104
Bulb
Bristol
H23B18SABCX
Reciprocating
Internal
30/370
34
A112103
Electronic
Bristol
H23B18SABCX
Reciprocating
Internal
30/370
34
A112103
Electronic
Bristol
H29B24UABCX
Reciprocating
Internal
30/370
33.5
A112114
Bulb
Installation Instructions
Kit Type
Part Number
A
309000906
A
309000906
A
309000906
A
309000906
A
309000906
Control Thermostat Location
Diagram
Page 34 Page 34 Page 34 Page 34 Page 34
Condenser Fan and
Evaporator Blower Location
Diagram
Page 36 Page 36 Page 36 Page 36 Page 36
