7
To adjust the door stop:
Door stop is adjustable between 85 to 145
degrees.
1 Open door to provide access to screw.
2 Loosen screw.
3 Adjust door to desired location.
4 Rotate door stop until it makes contact
with the lower hinge.
5 Re-tighten screw.
INSTALLATION
NOTE
View shown is looking up at the bottom of
the refrigerator door.
6 Ensure door stops in desired location
before resuming normal use.
To level the doors using the adjustable
lower hinge (select models):
1 Remove all food items from door bins on
door being adjusted.
2 Open doors to 90 degrees.
NOTE
Adjustable hinge should only be used after
doors have been leveled with rollers.
Adjusting Door
Rotate
Door to Desired
Location
Re-tighten Screw
Rotate Door
Stop
Re-tighten
Screw
Adjustable Door Stop
Door
Stop
Screw
Lower
Hinge
Min
Open
Max
Open
Open
Door
90
Degrees
Bottom of Door
To Next Page
