Electrolux IB4 2310 - Method of Use; Description of the Machine

1006
1
3
D0348
12 34
D0343
Notice Date Page
01405013
INSTRUCTION
HANDBOOK
3. Method of use
Description of the machine
Pivoting sensitive
protective device (fi nger
guard)
Insertion table
Conrol
pedal
Bed release device
(to be used in case of power failure)
Control device
Reception
tray
Cylinder
Thermostat
"On" indicator lamp
"On-Off" switch
"Heating" indicator lamp
Potentiometer button
"Ironing speed adjustment" (option
with variator, speed adjustment from
1 to 4 m/min.)
1.
2.
3.
4.
5.
