BBaassiicc IInnffoorrmmaattiioonn
1-3
SSaaffee SSeerrvviicciinngg PPrraaccttiicceess
AAvvooiidd ppeerrssoonnaall iinnjjuurryy aanndd//oorr pprrooppeerrttyy ddaammaaggee bbyy
oobbsseerrvviinngg iimmppoorrttaanntt SSaaffee SSeerrvviicciinngg PPrraaccttiicceess..
FFoollllo
owwiinngg aarree ssoommee lliimmiitteedd eexxaammpplleess ooff ssaaffee pprraaccttiicceess::
1. DO NOT attempt a product repair if you have any
doubts as to your ability to complete the repair in a
safe and satisfactory manner.
2. Always Use The Correct Replacement Parts as indi-
cated in the parts documentation. Substitutions
may defeat compliance with Safety Standards Set
For Home Appliances. Do not exceed maximum
recommended wattage on halogen bulb replace-
ments. Doing so could blow fuses and/or damage
transformers.
3. Before servicing or moving an appliance:
• Remove power cord from the electrical outlet, trip
circuit breaker to the OFF position, or remove fuse.
• Turn off water supply.
4. Never interfere with the proper operation of any
safety device.
5. Use ONLY REPLACEMENT PARTS CATALOGED
FOR THIS APPLIANCE. Substitutions may defeat
compliance with Safety Standards Set For Home
Appliances.
6. GROUNDING: The standard color coding for safety
ground wires is GREEN, or GREEN with YELLOW
STRIPES. Ground leads are not to be used as cur-
rent carrying conductors. It is EXTREMELY impor-
tant that the service technician reestablish all safety
grounds prior to completion of service. Failure to
do so will create a hazard.
7. Prior to returning the product to service, ensure
that:
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and
secured away from sharp edges, high-temperature
components, and moving parts.
• All non-insulated electrical terminals, connectors,
heaters, etc. are adequately spaced away from all
metal parts and panels.
• All safety grounds (both internal and external) are
correctly and securely connected.
• All panels are properly and securely reassembled
SSeeccttiioonn 44 -- CCoommppoonneenntt TTeeaarrddoowwnn
((CCoonnttiinnuueedd))
Internal Cabinet Components................................ 4-13
Coffee Grounds Drawer .................................... 4-13
Brewing Unit Door Removal ............................ 4-13
Capacitor Removal .......................................... 4-14
Voltage Transformer Removal .......................... 4-14
Microswitch Removal........................................ 4-14
Control Board Removal .................................... 4-15
Grinder Assembly Removal .............................. 4-16
Grinder Adjustment Screw Removal ................ 4-16
Grinder Assembly Breakdown ........................ 4-17
Brewing Assembly Removal ............................ 4-18
Low Pressure Flow Meter Removal.................. 4-19
Magnetic Sensor Removal................................ 4-19
Water Pump Assembly Removal ...................... 4-20
2-Way Solenoid Removal ................................ 4-20
3-Way Solenoid and Drain Tube Removal ...... 4-21
Boiler Assembly Removal ................................ 4-21
SSeeccttiioonn 44 -- PPaarrttss LLiissttss aanndd EExxppllooddeedd VViieewwss
........
55--11
Electrical Components Exploded View ................ 5-2
Electrical Components Parts List ........................ 5-3
Water System Components Exploded View ........ 5-4
Water System Components Parts List ................ 5-5
Boiler Assembly Exploded View ............................ 5-6
Boiler Assembly Parts List .................................... 5-7
Grinder Assembly Exploded View ........................ 5-6
Grinder Assembly Parts List ................................ 5-7
Brewing Assembly Exploded View ........................ 5-8
Brewing Assembly Parts List ................................ 5-9
Door Assembly Exploded View ............................ 5-10
Door Assembly Parts List ...................................... 5-11
Miscellaneous Components Exploded View ........ 5-12
Miscellaneous Components Parts List .................. 5-13
SSeeccttiioonn 66 -- WWiirriinngg DDiiaaggrraammss
..................................
66--11
Wiring Diagram .................................................... 6-2
To Next Page
