A.2 TECHNICAL DATA
A.2.1 MATERIALS AND FLUIDS USED
The areas in contact with the product are in non-toxic plastic
material for the
ventilated models; and in galvanised iron
protected with stove baked transparent paint, with non-toxic
characteristics in compliance with current standards, for the
models with
evaporating grille ; the “ Wine-Line ” models are in
steel, prepainted black on the outside, whereas the inside
compartment is in polystyrene, which is the best solution for
cleaning and hygiene. An HFC refrigerant fluid complying with
the current regulations is used in the refrigerating units. The type
and quantity of gas used are given on the dataplate.
A.2.2 DIMENSIONS, PERFORMANCE AND CONSUMPTION
TECHNICAL CHARACTERISTICS (common to all models)
“Prepainted/Wine” “Fish/Aisi”
External dimensions:
- width mm 703 703
- depth mm 619 619
- height mm 1640 1755
Compartment dimensions:
- width mm 610 610
- depth mm 435435
- height mm 1450 1450
Gross capacity l 400 400
Max. room temp. °C +32+32
Power supply voltage(50Hz) V 230230
Fully insulated door refrigerated models “0°C/+10°C”
Consumption kwh/24h 2.55
Temp. range. in compartment °C 0/+10
Room temperature °C 43
Refrigeration system ventilated
Plastic-coated racks mm: 600x400 no. 4
Total power W 163
Qty refrigerant (R134a) g. 240
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(¹) The value could increase depending on the workplace
where measured.
Refrigerated models with glass door “0°C/+10°C”
Consumption kwh/24h 3.66
Temp. range in compartment °C 0/+10
Room temperature °C 32
Refrigeration system ventilated
Plastic-coated racks mm: 600x400 no. 4
Total power W 193
Qty refrigerant (R134a) g. 240
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(¹) The value could increase depending on the workplace
where measured.
Refrigerated models “-2°C/+8°C” (high humidity)
Consumption kwh/24h 8.26
Temp. range in compartment °C -2/+8
Room temperature °C 43
Refrigeration system ventilated
Plastic-coated racks mm: 600x400 no. 4
Total power W 385
Qty refrigerant (R134a) g. 200
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(¹) The value could increase depending on the workplace
where measured.
Freezer models with fully insulated door
Consumption kwh/24h 9.71
Temp. range in compartment °C -24/-15
Room temperature °C 3
8
Evaporating grilles (*) mm: 600x400 no. 4
Total power W 527
Qty refrigerant (R404A) g. 240
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(*) fixed evaporating grilles in steel coated with non-toxic paint.
(¹) The value could increase depending on the workplace
where measured.
Freezer models with glass door
Energy consumption at 32°C kwh/24h 12.85
Temp. range in compartment °C -22/-15
Room temperature °C 32
Refrigeration system static
Evaporating grilles (*) mm: 600x400 no. 4
Power W 850
Qty refrigerant (R404A) g. 240
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(*) fixed evaporating grilles in steel coated with non-toxic paint.
(¹) The value could increase depending on the workplace
where measured.
“Wine-Line” models
Consumption kwh/24h 2.7
Temp. range in compartment °C (**)
Plastic-coated racks mm: 600x400 no. 4
Total power W 205
Qty refrigerant (R134a) g. 210
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(**) see par. 4.1
(¹) The value could increase depending on the workplace
where measured.
Fish models
Consumption kwh/24h 7.7
Temp. range in compartment °C -7/+6
Room temperature °C 38
Refrigeration system ventilated
Trays: H=210 n 4
Trays: H=200 n 1
Total power W 350
Qty refrigerant (R134a) g. 200
Protection rating IP 20
Equivalent sound pressure
level Leq (¹) dB(A) <70
(¹) The value could increase depending on the workplace
where measured.
A.2.3 MECHANICAL SAFETY CHARACTERISTICS,
HAZARDS
The appliance does not have sharp edges or protruding parts.
The guards for the moving and live parts are fixed to the cabinet
with screws to prevent accidental access.
A.2.4 CLIMATIC CLASS
The climatic class given on the dataplate refers to the following
values:
• for fully insulated door refrigerated, high humidity, fully
insulated door freezer, fish models
CLIMATIC CLASS: 5
43°C (EN 60335-2-89)
40°C room with 40% relative humidity (EN ISO 23953).
