Electrolux RM 4185 - Technical Descriptions; Block Diagram

3.0 Technical Descriptions
3.1 Block Diagram
The following diagram shows the AES II system components:
5
Display Modul
Power Modul
Solar input
230 V~
12 V -
D+ (generator)
Reigniter
Thermocurrent
adapter
Heating element DC
Heating element AC
