15. Place the upper door on the middle
hinge pivot (12).
16. Fix the door with upper hinge and fix it
with screws of it (13).
17. Attach the door handles and plugs on
the opposite side.
Do a final check to make sure
that:
• All screws are tightened.
• The magnetic seal
adheres to the cabinet.
• The door opens and
closes correctly.
If the ambient temperature is
cold (i.e. in Winter), the
gasket may not fit perfectly to
the cabinet. In that case, wait
for the natural fitting of the
gasket.
In case you do not want to
carry out the above
mentioned operations,
contact the nearest
Authorised Service Centre.
The Authorised Service
specialist will carry out the
reversibility of the doors at
your cost.
