INSTRUCTION SHEET
©2021 Electrolux Home Products, Inc. Instruction Sheet A00343905 7.23.21
Single Trim Kits (79" & 84" Tall Cabinet Cutouts)
Min. 35.01"
Max. 35.57"
Min. 79.22"
Max. 80.18"
Min. 36.88"
Max. 37.67"
Min. 83.88"
Max. 84.85"
TRMKTEZ1FL79 (Frigidaire) TRMKTSS1LV84 (Electrolux)
33" +/- 0.032"
79" +/- 0.06"
25.25"
minimum
1.021"
minimum
(25.9 mm)
35.5" +/- 0.032"
83.75" +/- 0.06"
24"
minimum
0.706"
minimum
(17.9 mm)
IMPORTANT
Make sure there are two separate dedicated grounding-type duplex wall outlets for the freezer and the refrigerator as specified in the Use & Care Manual.
