Electrolux WA GL4 E 201 - TECHNICAL INFORMATION; PRODUCT DESCRIPTION

TECHNICAL INFORMATION
Dimensions Width / Height / Depth 605 / 850 / 605 mm
Total depth 640 mm
Electrical connection: Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and mois-
ture ensured by the protective cover, except where the low volt-
age equipment has no protection against moisture
IPX4
Water supply pressure Minimum 0,5 bar (0,05 MPa)
Maximum 8 bar (0,8 MPa)
Water supply
1)
Cold water
Maximum load Cotton 8 kg
Spin speed Maximum 1400 rpm (WA GL4 E 201)
1600 rpm (WA GL6 E 201)
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
PRODUCT DESCRIPTION
1 2 3 8
9
5
6
7
4
1
0
1
1
1
2
1
Worktop
2
Detergent dispenser
3
Control panel
4
Door handle
5
Rating plate
6
Drain pump
7
Feet for the appliance level
8
Water drain hose
9
Water inlet valve
10
Mains cable
11
Transit bolts
12
Feet for the appliance level
electrolux 5
