5. Take out the laundry and then close
the appliance door.
6. Close the filter flap.
15. TECHNICAL DATA
Dimension Width/ Height/ Depth/
Total depth
600 mm/ 850 mm/ 605 mm/ 639
mm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid parti-
cles and moisture ensured by the protective cov-
er, except where the low voltage equipment has
no protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0,5 bar (0,05 MPa)
8 bar (0,8 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 9 kg
Energy Efficiency Class A+++
Spin Speed Maximum 1600 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
16.
