Electrolux WDU4100 - Specifications

General Features and Parts
Specifications
STOPPER
REMOVABLE SPLASH GUARD
SINK FLANGE
DIAMETER 3
3
/8 X 12 THREADS/INCH
RUBBER SINK FLANGE GASKET
FIBER GASKET
SUPPORT RING
NOTE ARROWS INDICATING UP
MOUNT RING
TIGHTENING EARS
CUSHION MOUNT
DISHWASHER DISCHARGE INLET
ELBOW GASKET
SCREWS
ELBOW
FLANGE
END BELL
(ELECTRICAL CONNECTIONS)
Z
GROOVE G
HOPPER
DISHCHARGE ELBOW
Y
SINK
Electrical specifications are on the disposer rating label.
Dimensions
Some Typical Installations
“E”
1
1
/2”
(38mm)
BPS
“B”
“D”
“C”
“A”
SINGLE BOWL DOUBLE BOWL / CENTRE OUTLET DOUBLE BOWL / END OUTLET
10” (254 mm)
APPROX.
10” (254 mm)
APPROX.
10” (254 mm)
APPROX.
MODEL “A” “B” “C” “D” “E”
WDU4100
Inches 14
1
/16 6
15
/16 5
3
/16 5
1
/16 2
3
/4
mm 357 176 132 129 70
WDU4400
Inches 15
1
/8 7
1
/4 8
5
/8 5
9
/16 2
3
/4
mm 384 184 219 141 70
3
